BeamZPRO Brute 20000FB4 Pure Diode Laser Outdoor
Brute 20000FB4 is an IP65 RGB diode laser with a guaranteed 20W output. Analogue modulation provides continuous colour fading, while 35 kpps scanners at 8° support precise graphics and beam effects. Applications include fixed installations, mobile productions, multimedia and long-distance outdoor projection.
The integrated Pangolin FB4 controller supports network-based operation with Art-Net and sACN; automatic standalone operation is also available. EtherCON networking, an ILDA output, interlock connections and Scan Fail Safety are provided. The aluminium housing and temperature-controlled low-noise fan support indoor and outdoor use. Image size and X/Y inversion can be adjusted to suit the setup.
Highlights
- Full-colour semiconductor diode laser with IP65 enclosure
- Laser sources: red 4,000 mW, green 4,000 mW, blue 12,000 mW
- Guaranteed combined output: 20W
- Integrated Pangolin FB4 control
- EtherCON network input/output
- Art-Net and sACN capability
- Dust-protected aluminium housing
- OLED display
- Emergency-stop interlock input/output over EtherCON
- Scan Fail Safety system
- Optical scanners: 35 kpps at 8°
- Maximum scanning angle: 50°
- Low-noise temperature-controlled fan
- ILDA output
- Image-size adjustment and X/Y inversion
- Analogue RGB modulation
- TR1 power input/output
Specifications
General
- Brand: beamZ Professional
- Product series: Brute series
- Model: Brute 20000FB4
- Manufacturer item number: 152.571
- Colour: Black
Light source
- Laser guaranteed output: 20,000 mW
- Laser red: 4,000 mW @ 638 nm
- Laser green: 4,000 mW @ 525 nm
- Laser blue: 12,000 mW @ 455 nm
- Laser maximum output: 20,000 mW
Optics
- Laser scanner system: 35 kpps @ 8°
- Maximum laser scan angle: 50°
Movement
- X/Y adjustment: Image size and axis inversion
Features
- Colour modulation: Analogue RGB
Control
- DMX channels: 10 or 34
- Control modes: Pangolin FB4, Auto programmes, DMX, Art-Net, sACN; ILDA listed in manufacturer control-mode table
- RDM: No
Input connections
- Power: 1x TR1 IP65, type A
- Network: 1x RJ45 / EtherCON
- Interlock: 1x RJ45 / EtherCON
Output connections
- Power: 1x TR1 IP65, type B
- Network: 1x RJ45 / EtherCON
- ILDA: 1x DB25, female
- Interlock: 1x RJ45 / EtherCON
Hardware features
- Cooling: Temperature controlled fan
- Display type: OLED
- Scanner safety: Scan Fail Safety
Environmental
Electrical
- Power supply: 100–240 V AC, 50/60 Hz
Mechanical
- Dimensions without bracket (W x D x H): 205 x 285 x 186 mm
- Net weight without bracket: 9.3 kg
