BeamZPRO NEUTRON-DOT TM Linkable 60W WW+Amber+RGB
NEUTRON-DOT TM combines a warm-white/amber blinder source with pixel-controllable RGB Aura backlighting. Its compact hybrid design supports audience-blinder effects, strobing, stage washes, decorative effects and LED pixel mapping.
The coupling system connects fixtures into bars, arrays and other shapes. The IP65 aluminium construction is specified for indoor and outdoor use, with an operating range of −20 to +40 °C. OLED controls include a key lock and reversible display orientation. A 23° beam, 16-bit PWM dimming, DMX/RDM and weatherproof connections provide practical production control.
Highlights
- 60W warm-white/amber source; warm-white colour temperature 2,700 K
- RGB Aura backlight with pixel control
- Compact aluminium housing
- Indoor/outdoor IP65 enclosure
- Beam angle: 23°
- 16-bit PWM dimming
- Coupling system with two coupling parts included
- OLED control panel
- Key lock and reversible display
- Automatic operating mode
- Convection cooling
- Weatherproof DMX and TR1 power input/output
- Blinder, strobe, wash, pixel-mapping and decorative effects
- Fixtures combine into bars, arrays and other shapes
Specifications
General
- Brand: beamZ Professional
- Product series: Neutron series
- Model: NEUTRON-DOT TM
- Manufacturer item number: 151.524
- Colour: Black
Light source
- Light source: Blinder: 1x 60W WW/amber LED
- Light source: Backlight: 16x 0.5W RGB LED
- Illuminance: 18,908 lx @ 1 m
- Warm-white colour temperature: 2,700 K
Optics
Features
- Flash per second: 0–20 Hz
- Dimming: 16-bit PWM
Control
- DMX channels: 4, 9, 11, 15, 18, 52 or 63
- Control modes: Auto programmes, DMX, Manual; RDM supported
Input connections
- Power: 1x TR1 IP65, type A
- DMX: 1x 5-pin XLR IP65, male
Output connections
- Power: 1x TR1 IP65, type B
- DMX: 1x 5-pin XLR IP65, female
Hardware features
- Display type: OLED with key lock and reversible display
- Cooling: Convection
- Accessory reference: 177.923, as listed by manufacturer
Environmental
- IP rating: IP65
- Operating temperature: −20 to +40 °C
Electrical
- Power supply: 100–240 V AC, 50/60 Hz
Mechanical
- Dimensions (W x D x H): 218 x 142 x 142 mm
- Net weight: 2.7 kg
Included accessories
- Two coupling parts
- Mounting bracket
- Adapter for individual mounting
