BeamZPRO NEUTRON-BOLD FC Linkable 600W RGBAL+RGB
NEUTRON-BOLD FC combines a 600W RGBAL blinder source with 72 RGB Aura LEDs for pixel-controlled backlighting. It supports audience-blinder effects, strobing, stage washes, decorative effects and LED pixel mapping in a modular IP65 fixture.
The coupling system allows multiple fixtures to form bars, arrays and other shapes. DMX, Art-Net and sACN support larger lighting setups. A reversible OLED display with key lock, 16-bit PWM dimming, temperature-controlled cooling and weatherproof connections aid installation and operation. Mounting parts and an adapter for individual use are included.
Highlights
- 600W RGBAL source for full-colour blinder effects
- 72 pixel-controllable RGB Aura LEDs
- Aluminium body for stage and event use
- Indoor/outdoor IP65 enclosure
- Beam angle: 23°
- 16-bit PWM dimming
- Coupling system for fixture arrays
- OLED control panel
- Key lock and reversible display
- Temperature-controlled fan cooling
- Automatic mode listed among product highlights
- Weatherproof DMX and TR1 power input/output
- Mounting bracket and adapter for individual use included
- Blinder, strobe, wash, pixel-mapping and decorative effects
- DMX, Art-Net and sACN control
Specifications
General
- Brand: beamZ Professional
- Product series: Neutron series
- Model: NEUTRON-BOLD FC
- Manufacturer item number: 151.544
- Colour: Black
Light source
- Light source: Blinder: 1x 600W RGBAL LED
- Light source: Backlight: 72x 0.5W RGB LED
Optics
Features
- Flash per second: 1–20 Hz
- Dimming: 16-bit PWM
Control
- DMX channels: 6, 8, 14, 21, 24, 223 or 235
- Control modes: DMX, Manual, Art-Net, sACN
Input connections
- Power: 1x TR1 IP65, type A
- DMX: 1x 3-pin XLR IP65, male
- DMX: 1x 5-pin XLR IP65, male
- Data: 1x RJ45 IP65
Output connections
- Power: 1x TR1 IP65, type B
- DMX: 1x 3-pin XLR IP65, female
- DMX: 1x 5-pin XLR IP65, female
- Data: 1x RJ45 IP65
Hardware features
- Cooling: Temperature controlled fan
- Display type: OLED with key lock and reversible display
Environmental
Mechanical
- Dimensions (W x D x H): 330 x 377 x 307 mm
- Net weight: 13.4 kg
Included accessories
- Mounting bracket
- Adapter for individual mounting
