The PDC90 is a compact stereo media player with a built-in class-D amplifier. This All-in-one player is equipped with a DAB+ tuner, a USB slot and a BT receiver to stream music directly from your smartphone/tablet to the player. The front features a 3.5 mm auxiliary input and the back is equipped with 3 balanced inputs with phantom power that can be adjusted with Mic/Line dip switches and 2 unbalanced RCA stereo inputs.
Multifunctional media player with Class-D amplifier
Integrated DAB+ tuner
BT-receiver for streaming audio
USB media player with display
1x 3.5mm Aux input
3x Mic/Line inputs (XLR) with phantom power
VOX priority on Mic/Line1 with mute level control
Mix output balanced XLR
RCA pre-amplifier output
24V DC Mute control input
Separate level control per input
Treble and bass control
Remote control for MP3 player
Brand Power Dynamics
Product colour Black
Playback options BT 5.0 streaming, USB, DAB+ radio, Line input, Microphone (input)
Frequency response 100Hz - 20.000Hz
THD <2%
Signal-to-noise ratio: Mic >80dB
Signal-to-noise ratio: Line >80dB
Output level: Nominal 0dBV
Input connections 3.5mm Jack, RCA, USB, XLR (3-pin)
Output connections RCA, Screw terminal, XLR (3-pin)
Output channels 2
Output power: RMS 60W
Power supply 100-240VAC 50/60Hz
19 Inch Yes
Dimensions (L x W x H) 135 x 483 x 45mm
Weight (kg) 1.9
Included accessories Remote control (wireless), Power cable
